AV40-11、AV40-12
shangu
The scope of supply includes fan host, gearbox, motor, power oil station, lubricating oil station, high and low voltage cabinet, automatic control and electric control. At the same time, we can provide civil engineering design, installation and commissioning guidance for customers according to their blast furnace parameters.
Av40-10 parameters are as follows:
Inlet flow: 1275m ³/ Mm maximum allowable operating temperature: 260 ℃
Inlet pressure: 0.0988mpa maximum continuous speed: 8190r / min
Outlet pressure: 0.3 MPa spindle speed: 7800r / min
Shaft power: 3550kw
AV40-11 parameters are as follows:
Inlet flow: 1500m ³/ Mm maximum allowable operating temperature: 260 ℃
Inlet pressure: 0.0988mpa maximum continuous speed: 7800r / min
Outlet pressure: 0.35Mpa spindle speed: 7800r / min
Shaft power: 6000kW
Av40-13 parameters are as follows:
Inlet flow: 1794m ³/ Mm maximum allowable operating temperature: 260 ℃
Inlet pressure: 0.096mpa maximum continuous speed: 7800r / min
Outlet pressure: 0.4MPa spindle speed: 7800r / min
Shaft power: 6052kw
The scope of supply includes fan host, gearbox, motor, power oil station, lubricating oil station, high and low voltage cabinet, automatic control and electric control. At the same time, we can provide civil engineering design, installation and commissioning guidance for customers according to their blast furnace parameters.
Av40-10 parameters are as follows:
Inlet flow: 1275m ³/ Mm maximum allowable operating temperature: 260 ℃
Inlet pressure: 0.0988mpa maximum continuous speed: 8190r / min
Outlet pressure: 0.3 MPa spindle speed: 7800r / min
Shaft power: 3550kw
AV40-11 parameters are as follows:
Inlet flow: 1500m ³/ Mm maximum allowable operating temperature: 260 ℃
Inlet pressure: 0.0988mpa maximum continuous speed: 7800r / min
Outlet pressure: 0.35Mpa spindle speed: 7800r / min
Shaft power: 6000kW
Av40-13 parameters are as follows:
Inlet flow: 1794m ³/ Mm maximum allowable operating temperature: 260 ℃
Inlet pressure: 0.096mpa maximum continuous speed: 7800r / min
Outlet pressure: 0.4MPa spindle speed: 7800r / min
Shaft power: 6052kw
