Serial number | name | Company | Parameters | remarks |
1 | Inner diameter of furnace shell | mm | Φfour thousand | |
2 | Rated capacity | t | 25 | |
3 | Maximum capacity | t | 33 | |
4 | Rated capacity of transformer | MVA | 12.5 | Top outlet |
5 | Transformer primary voltage | V | 6300 | |
6 | Transformer secondary voltage | V | undetermined | |
7 | Transformer voltage regulation mode | No load electric | ||
8 | frequency | Hz | 50 | |
9 | Graphite electrode diameter | mm | Φfour hundred | |
10 | Diameter of electrode distribution circle | mm | Φeight hundred | |
11 | Maximum moving distance of electrode | mm | 2800 | |
12 | Maximum moving speed of electrode (rise / fall) | mm/min | 6000/4500 | (manual) |
13 | Tilting angle | 20° (tapping) 12° (slag discharge) | ||
14 | Lifting height of furnace cover | mm | 400 | |
15 | Size of slag discharge door (width)×High) | mm×mm | 1000×eight hundred | |
16 | Opening angle of furnace cover | 62° | ||
17 | Water consumption | m3/h | 300 | |
Working pressure of hydraulic device | MPa | 12 | ||
18 | Hydraulic medium | Water glycol | ||
19 | Water inlet pressure of water cooling device | MPa | 0.2~0.3/0.45 | Open / closed loop |
20 | Compressed air pressure | MPa | 0.4-~0.6 | |
21 | Operation mode | Left and right | ||
22 | oxygen consumption for oxygen lancing | Nm3 / ton steel | 50 | |
23 | Furnace door oxygen lance | 1set | ||
24 | Smelting time | min | 100 | Feeding times: 2 times |
