Technical parameters of 4500kva silicon manganese furnace:
Transformer capacity: 4500kva
Primary side voltage: 11kv
Secondary side voltage: 94 ～ 102 ～ 122 (V)
Secondary side voltage level: 8, level difference: 4V
Common voltage: 102 (V)
Electrode diameter: Ф 720㎜
Diameter of electrode center circle: Ф 1750（㎜）
Furnace diameter: Ф 4200（㎜）
Furnace depth: 1700mm
Shell diameter: Ф 5700㎜
Furnace shell height: 3500 mm
Height of low smoke hood: 1500mm
Electrode stroke: 1200 mm
Electrode lifting speed: 0.5m/min
Cooling water consumption: 280t / h
Technical parameters of 4500kva silicon manganese furnace:
Transformer capacity: 4500kva
Primary side voltage: 11kv
Secondary side voltage: 94 ～ 102 ～ 122 (V)
Secondary side voltage level: 8, level difference: 4V
Common voltage: 102 (V)
Electrode diameter: Ф 720㎜
Diameter of electrode center circle: Ф 1750（㎜）
Furnace diameter: Ф 4200（㎜）
Furnace depth: 1700mm
Shell diameter: Ф 5700㎜
Furnace shell height: 3500 mm
Height of low smoke hood: 1500mm
Electrode stroke: 1200 mm
Electrode lifting speed: 0.5m/min
Cooling water consumption: 280t / h
